LOCKING RANGE STROKE WEIGHT
12.5-51.0 mm ID 20 mm 5.5 Kgs

FIN FAN TUBE OD SUPPORT
FACER BUSH SIZE
HOLDER INCH MM GUAGE

FFF - 100 1" 25.4 12-23 1.1/8"
FFF - 118 1.1/8" 28.58 11-23 1.1/4"

FFF - 114 1.1/4" 31.75 11-23 1.3/8"

FFF - 112 1.1/2" 38.10 11-23 1.5/8"

FFF - 134 1.3/4" 44.45 09-23 1.7/8"
FFF - 200 2" 50.8 09-23 2.1/8"

TUBE OD SUPPORT
FIN FAN BUSH SIZE
INCH MM GUAGE

FFW - 100 1" 25.4 12-23 1.1/8"

FFW - 118 1.1/8" 28.58 11-23 1.1/4"

FFW - 114 1.1/4" 31.75 11-23 1.3/8"
FFW - 112 1.1/2" 38.10 11-23 1.5/8"

FFW - 134 1.3/4" 44.45 09-23 1.7/8"

FFW - 200 2" 50.8 09-23 2.1/8"
