RE-TUBING TOOLS
Continuous Tube Puller
- Best suitable for big shutdown jobs.
- Remove tubes continuously without damage to the tube sheet.
- Interchangeable Pulling Guns with same powerpack.
- Available in a fully pneumatic version also.
Auto Puller – 15
- Max Capacity : 15 Tons
- Tube Capacity : 1” Max
- Pulling speed : 5 Mtr/ min
- Weight : 26 Kgs
- Suitable for use with Tube Runner -5 & 9
Auto Puller – 30
- Max Capacity : 30 Tons
- Tube Capacity : 1.1/2” Max
- Pulling speed : 3 Mtr/ min
- Weight : 38 Kgs
- Suitable for use with Tube Runner -5 & 9
Auto Puller – 45
- Max Capacity : 45 Tons
- Tube Capacity : 3” Max
- Pulling speed : 2 Mtr/ min
- Weight : 78 Kgs
- Suitable for use with Tube Runner -5 & 9
Continuous Puller Power Units
Tube Runner – 5
Automatic Tube Pulling Powerpack
- 3 Phase 415V, 3.7KW , 5 H.P
- Max Working pressure : 350 Bar
- Weight : 220 Kgs
- Dimension : 1020 x 680 x 960 mm
- Suitable for use with Auto Puller -15 / 30 /45
Tube Runner – 9
Automatic Tube Pulling Powerpack (Pneumatic)
No Electric supply required.
Fully Pneumatic controls.
Suitable for use in Hazardous conditions.
- Air Supply of 275 cfm@ 90 psi ,9 H.P
- Max Working pressure : 350 Bar
- Weight : 220 Kgs
- Dimension : 1020 x 680 x 960 mm
- Suitable for use with Auto Puller -15 / 30 /45
Stub Puller
FOR REMOVAL OF CUT STUBS FROM TUBE SHEET OF U Tube Bundles
- Available in Electric and Pneumatic options.
- Interchangeable Pulling Guns with same powerpack.
- Removes stubs without damaging tube sheet.
Stub Puller – 15
- Max Capacity : 15 Tons
- Tube Capacity : 1.1/2” Max
- Weight : 26 Kgs
- Suitable for use with Tube Runner -2 & 3
Stub Puller – 30
- Max Capacity : 30 Tons
- Tube Capacity : 3” Max
- Weight : 32 Kgs
- Suitable for use with Tube Runner – 2 & 3
Stub Puller – 45
- Max Capacity : 45 Tons
- Tube Capacity : 3” Max
- Weight : 65 Kgs
- Suitable for use with Tube Runner – 2 & 3
Stub Puller Power Units
Tube Runner – 2
Semi- Automatic Tube Pulling Powerpack
- 3 Phase 415V, 3.7KW , 2 H.P
- Max Working pressure : 350 Bar
- Weight : 70 Kgs
- Dimension :520 x 320 x 580 mm
- Suitable for use with Stub Puller -15 / 30 /45
Tube Runner – 3
Semi- Automatic Tube Pulling Powerpack
- 3 Phase 415V, 3.7KW ,3 H.P
- Max Working pressure : 350 Bar
- Weight : 120 Kgs
- Dimension : 575 x 320 x 7865 mm
- Suitable for use with Auto Puller -15 / 30 /45
EXTRACTOR (Auto Grip Puller)
Air Hydraulic Stub Puller
Max Capacity : 9 ton
Tube Capacity: 5/8” to 1.1/2”
Weight: 18.5 kg
Suitable Power unit : Air-Hydraulic Intensifier
Tube Pulling Consumables
Manual Tube Removing Tools
Wall Reducer
HSS Reamer comes with a mores taper to fit in a standard drill machine. Front end is grounded as per tube gauge to facilitate reduction of tube thickness thereby weakening expansion joint.
Size : ⅜” to 4” OD
Knockout Tool
Built from high Impact steel for knocking out the tubes from the tube sheet with Pneumatic Hammer.
Size : ⅜” to 4” OD
Tube Drift / Collapsing Tool
Used for Collapsing tubes made thinner using tube wall reduce for driving the tubes out of tube sheet. Preferably to be used with Pneumatic Chipping Hammer.
Size : ⅜” to 2.½” OD
Manual Tube Puller
Ideally suitable for small maintenance jobs. Allows easy removal of stubs and tubes.
Can be used with an impact wrench.
Size : ¼” to 1” OD
Internal Tube Cutters
ATP Series
ATP Series Tube Cutters are designed for quick cutting of ferrous and non ferrous tubes.
Size : ⅝” TO 1.½” OD
Standard reach available : 4”
OTC Series
OTC series is designed for hand operation using ratchet or hand wrench for cutting ferrous and non ferrous tubes.
Size : ⅝” to 2.½” OD
Standard reach available : 6”
PR-68 Series
PR -68 Series cutters are ideal for cutting thick walled boiler tubes.
Size : 20 to 105 mm ID
Standard reach available : 4”
